Magnetic Bead-based Plasmid Extraction Kit
This kit adopts the alkaline lysis method to lyse bacterial cells and isolates plasmid DNA via magnetic bead technology. It enables the extraction of high-purity plasmid DNA from bacterial cultures of various volumes.The functional groups modified on the magnetic bead surface feature strong specific adsorption capacity for plasmid DNA under defined conditions. By adjusting ambient conditions, plasmid DNA can be eluted from the beads, achieving rapid separation and purification.DNA extracted with this kit is suitable for a wide range of molecular biology experiments, including sequencing, enzyme digestion, ligation, transformation, library screening and more.
Product Performance
Fast & Simple: Repeated centrifugation is not required; extraction of 96 samples can be completed within 1 hour.
High Yield: Uniquely encapsulated magnetic beads enable specific and efficient plasmid binding while reducing non-specific adsorption.
High Purity: Eluted plasmid can be directly used in downstream experiments such as enzyme digestion and sequencing.
High-throughput Compatible: Can be matched with Rebeads automated nucleic acid extractors.
Applications
Suitable for plasmid extraction from overnight-cultured E. coli. The yield and purity are comparable to traditional column-based extraction methods. It is applicable to routine molecular experiments including enzyme digestion, ligation, transformation, Sanger sequencing, library screening, etc.
Technical Parameters
| Product Name |
Catalog No. |
Specification |
Recommended Application |
| Dual Magnetic Bead Plasmid DNA Extraction Kit (Centrifugation-Free) |
SP103 |
100T / 300T |
Plasmid extraction |
| Magnetic Bead-based High-capacity Plasmid Extraction Kit |
SP102 |
100T / 300T |
Plasmid extraction |
| Magnetic Bead-based High-throughput Plasmid Extraction Kit |
SP106 |
100T / 300T |
Plasmid extraction |
| Magnetic Bead-based Endotoxin-free Maxi Plasmid Kit |
SP107 |
20T / 50T / 100T |
Endotoxin-free plasmid maxi prep |
| Magnetic Bead-based Endotoxin-free Mini Plasmid Kit |
SP134 |
96T / 3×96T |
Endotoxin-free plasmid mini prep |
| Magnetic Bead-based Endotoxin-free Midi Plasmid Kit |
SP144 |
20T / 50T / 100T |
Endotoxin-free plasmid midi prep |
Workflow
Application Case
Plasmid DNA Extraction — Comparison with Magnetic Bead Kits from Different Manufacturers
With the same bacterial dosage of 5 mL, plasmid extraction was performed using magnetic bead kits from three manufacturers.Elution volume was fixed at 100 μL, and 5 μL was loaded for agarose gel electrophoresis. The results show that Rebeads achieves higher plasmid yield than the other two brands.
Nucleic Acid Quantification Data
| Sample ID |
260/280 |
260/230 |
Conc. (ng/μL) |
Remark |
| 1 |
1.87 |
2.21 |
391.82 |
Rebeads |
| 2 |
1.88 |
2.19 |
392.75 |
Rebeads |
| 3 |
1.86 |
2.16 |
402.49 |
Rebeads |
| 4 |
1.92 |
1.78 |
93.41 |
Domestic Brand A |
| 5 |
1.91 |
1.77 |
94.05 |
Domestic Brand A |
| 6 |
1.93 |
1.84 |
91.27 |
Domestic Brand A |
| 7 |
1.88 |
1.53 |
55.95 |
Domestic Brand B |
| 8 |
1.87 |
1.55 |
56.03 |
Domestic Brand B |
| 9 |
1.86 |
1.56 |
55.35 |
Domestic Brand B |
Quantitative results indicate that the plasmid yield of the Rebeads kit is more than 3 times higher than Domestic Brand A and over 6 times higher than Domestic Brand B.
Precautions
When used with other reagents, strictly follow the corresponding experimental protocols.
Some buffer components in the kit contain irritant substances; please take proper protective measures during operation.
Magnetic bead residue may exist after elution; avoid sucking magnetic beads when pipetting samples.
This product is for research use only.
