Magnetic Bead-Based Whole Blood Genomic DNA Extraction Kit
This kit adopts the magnetic bead method to extract genomic DNA from fresh or frozen anticoagulated whole blood. Under high-salt conditions, DNA binds to the surface of silica-coated magnetic beads. Impure proteins and contaminants are removed through multiple washing steps, and target DNA is eluted under low-salt conditions.This method can extract 5–12 μg of high-quality and high-purity genomic DNA from 200 μL whole blood, suitable for downstream experiments such as sequencing, PCR, library construction, and Southern blotting.
Magnetic Bead-Based Whole Blood Genomic DNA Extraction Kit
Product Features
High purity and high yield of extracted DNA
One-step lysis and binding, no extra lysis operation required
High extraction efficiency for complex blood samples
Wide compatibility, applicable to both manual and automated workflows
Application
Suitable for manual and automated processing of blood samples.
Technical Parameters
| Components |
GP102-50 |
GP102-300 |
GP102-64 |
GP102-96 |
| Binding Solution |
30 mL |
180 mL |
580 μL×64 |
580 μL×96 |
| Washing Solution |
62 mL |
372 mL |
600 μL×4×64 |
600 μL×4×96 |
| Elution Buffer |
6 mL |
34 mL |
100 μL×64+1 mL |
100 μL×96+1 mL |
| Magnetic Bead Suspension |
1.05 mL |
6.2 mL |
1.35 mL |
1 mL×2 |
| Proteinase K |
1.05 mL |
6.2 mL |
1.35 mL |
1 mL×2 |
Workflow
Application Examples
Genomic DNA detection data extracted from 200 μL blood sample
Figure: Gel electrophoresis results of DNA extracted by the kit
(A260/280: 1.8–2.0, A260/230: around 2.0; DNA yield from 200 μL whole blood is more than 5 μg. Electrophoresis shows clear and bright DNA bands without smearing.)
Genomic DNA detection data extracted from 2 mL blood sample
Figure: Gel electrophoresis results of DNA extracted by the kit
(A260/280: 1.8–2.0, A260/230: around 2.0; Electrophoresis shows clear and bright DNA bands without smearing.)
Precautions
Do not freeze magnetic beads; fully mix the magnetic bead suspension before use.
Check all reagents for precipitation before use. If precipitate appears, redissolve in a 60°C water bath.
